Box Forklift Tempat Sampah Sampah

Rumah / Semua Lampiran / Box Forklift Tempat Sampah Sampah

Box Forklift Tempat Sampah Sampah

Komponen penting dari aplikasi dan konfigurasi produk

1, hydraulic system: seals are imported products; high-pressure hose with cone seal, high-performance import hose.
2, structural parts: the fork with alloy steel forgings, alloy steel high-performance aircraft body panels welded together.
3, mechanical performance: 73 ° cylinder can be achieved by adding forward check valve, can achieve long holding pressure, ensuring the safety or hose Baolie; Add a group can meet the requirements of asphalt .
4 Scope of application: applicable to the dumping of goods and efficient forward and so on, in particular, sanitation sector, thereby saving the manual handling and dumping of time.

Pressure for flow meter


Model

Pressure value(Bar)

Flow value(L/min)

Least

Maximum

Least

Recommend

Maximum

HW**F

35

160

19

38

57

Catatan


1, truk / daya dukung yang sebenarnya adalah pabrik komprehensif yang diperoleh dari forklift.
2, ini adalah peningkatan serasi pada kelompok 1 yang diperlukan forklift tambahan yang membutuhkan aspal.

Rincian Cepat


Tempat Asal: Fujian, Cina (Daratan)
Nama merek: HUAMAI
Model Number: HW30F-B1
Product Name: Type HW30F-B1forklift drop bottom box garbage dumpster
Type: HW30F-B1
Tingkat Instalasi: III
Adaptation Forklift: 3-4.5t
Omission from ET (mm): 353
Fork thickness T (mm): 55mm
Link distanceB (mm): 1016mm
Fork length C (mm): 1165mm
Frame width A (mm): 1100mm
Level Focus (mm): 312
