 Ketik ramp akses pengiriman muatan CRL8

Type: CRL8 Container Load Ramp


With a 3.0 metres overall length (1.5 metres of which is horizontal) this style allows easy placement and removal of the first and second line of pallets in a container. Fork pockets are provided either side of the ramp, along with flip-up front brackets. Securing chains both side prevent unintentional disengagement of the ramp from the container.

SPESIFIKASI


Model

 Size

Long x Wide x High (ground to ramp deck)

Kapasitas

SWL (KG)

Berat unit

 (KG)

Pengobatan permukaan

CRL8

3000*2320*160

8000

600

Enamel Paint Finish

Rincian Cepat


Tempat Asal: Fujian, Cina (Daratan)
Nama merek: HUAMAI
Model Number:CRL8
Product Name: Shipping container ramp
Type: CRL8
Size( Long x Wide x High): 3000*2320*160
SWL (kg): 8000kg
Unit Weight (kg): 600kg
Load Centre (mm): 1400mm


Pengantar]

HUAMAI container ramp is designed to allow your forklift access into standard shipping containers from ground level, as well as be used for vehicles loading from a raised dock. We typically supplied in 6500Kg or 1000Kg capacities to suit your operations, though others are available on request.

HUAMAI  container ramps are greatly appreciated in the markets based on the high quality and reliable performance.

Fitur:

* Bibir self-leveling dapat dilipat sehingga Anda dapat memindahkan atau menyimpan ramp wadah dengan lebih mudah.

* Ini memungkinkan untuk kapasitas muatan penuh saat di tanah yang sedikit tidak rata.

* Bagian belakang ramp kontainer diperkuat oleh baja untuk memastikan keamanan saat digunakan di bawah beban kerja terukur.

* Jalan Kontainer dapat dipindahkan dengan truk palet atau forklift melalui lubang.

* Bibir ramp ini berada di wadah, dan diamankan di tempat dengan kaki yang terkunci.
